Anotop 10mm Syringe Filter, 0.1um, 50 Pk

Thumbnail Filmstrip of Anotop 10mm Syringe Filter, 0.1um, 50 Pk Images

    Purchase Anotop 10mm Syringe Filter, 0.1um, 50 Pk

    Anotop 10mm Syringe Filter, 0.1um, 50 Pk
    Whatman SKU: 6809-1012

    $492.95
    Ships in 4 business days


    Whatman Anotop Aluminum Oxide Syringe Filters, 0.1 µm, 10 mm, 50/Pk - 6809-1012

    Whatman's Anotop line separates by physical particle dimension alone, a capability rooted in ceramic media chemistry rather than the organic polymer chemistries used in most other membrane technologies. A sterilizing-grade syringe filter delivers point-of-use sterile filtration in a single-use format, without the housing and gasket maintenance a reusable stainless steel filter holder requires. Rigid aluminum oxide holds a uniform capillary pore array and becomes visibly clear the moment it is wetted. The polypropylene housing presses snugly against the membrane during the pass while resisting degradation from routine sample matrices and delivers a chemically clean filtrate to the downstream step. Where bacterial contamination must stay out of the sample, manufacturer-tested retention keeps the instrument and downstream assay protected without a housing to maintain or clean.

    Membrane Characteristics

    • Mineral oxide chemistry gives proteins little to adsorb onto
    • Anodized alumina matrix contains no monomers, plasticizers, adhesives, or wetting agents
    • Chemical stability in aqueous solutions spans a pH 3 to 9 range
    • Rigid inorganic structure withstands high temperatures with minimal extractables
    • Uniform capillary pore array gives high pore density without lateral crossover

    Housing Characteristics

    • Thermal-bonded construction keeps adhesives out of the fluid path
    • Resists stress cracking from aqueous salt and buffer solutions
    • Housing rated for reliable filtration under syringe-applied backpressure at its maximum operating pressure
    • Standardized luer connection geometry provides secure engagement with standard syringe tips

    Particulates in your buffers and mobile phases shorten column life and unsettle your baselines. Reliable particulate removal protects your instruments and your data so column life and baseline stability stay predictable. Request a quote on bulk pricing for larger filtration orders from the Tisch Scientific team.

    For more information about chemical compatibility, please review our Chemical Compatibility Chart.

    Bubble Point (psi)
    6.2 bar (90 psi)
    Burst Pressure (psi)
    100psi
    Connection Type
    Luer-Lok/ Luer Slip
    Construction
    Anopore (Aluminum Oxide)
    Diameter
    10mm
    Filtration Area
    0.78cm²
    Holdup Volume
    <20µl
    Material
    Anopore
    Maximum Operating Pressure
    100psi
    Maximum Operating Temperature (°C)
    40°C
    Pack Count
    50
    Pore Size (µm)
    0.1
    Prefilter (Yes/No)
    No
    Sterility
    Nonsterile
    Volume Throughput (ml)
    Up to 10ml
    Wettability
    Hydrophilic
    • Single-Particle Analysis - Concentrates nanoparticles from dilute suspensions for tunable resistive pulse sensing and nanoparticle tracking.
    • AFM Sample Deposition - Removes large aggregates from colloidal suspensions before deposition on mica for atomic force microscopy surface imaging.
    • Electrolyte Clarification - Removes colloidal particles from electrochemical solutions for reproducible impedance and conductivity measurements.
    • HPLC Solvent Filtration - Filter chromatography mobile phases and solvents reliably, resisting degradation from aggressive organic reagents.
    • Carbohydrate Prep - Prepare saccharide samples for analysis, ensuring no organic extractables interfere with sensitive carbohydrate detection.
    • Gold Nanoparticle Prep - Removes large aggregate clusters from gold and silver nanoparticle suspensions before UV-Vis extinction and TEM sizing.
