AcroPak 1500 Capsules w/ Supor Membrane - 0.8/0.2um, Gamma-Irradiated , 1/Pk SKU: 12675

Supor (PES) Capsule Filters - 12675

Comprehensive manufacturer documentation and quality system traceability position Supor PES capsule filters for integration into regulated pharmaceutical manufacturing workflows. The Supor PES membrane platform scales consistently from laboratory evaluation through production implementation, with capsule effective filtration areas ranging from bench-scale to large-batch formats. Altogether, the result is a filtration process that eliminates cleaning validation, reduces changeover time, and provides batch-to-batch consistency through factory-tested, integrity-verified devices.

Key Supor (PES) Membrane Characteristics

• Rated for continuous operation at temperatures up to 60 degrees Celsius, the capsule maintains structural integrity and retention performance across the normal process temperature range.
• Supor PES membrane exhibits broad compatibility with aqueous buffers, aliphatic alcohols, and glycols across pH 1-14, supporting diverse pharmaceutical processing applications within a single membrane platform.
• Non-sterile capsule delivery is appropriate for clarification, prefiltration, and general laboratory applications where the filtrate does not require sterility assurance.
• The Supor membrane platform provides consistent filtration performance across capsule formats from laboratory-scale evaluation devices through production-scale large-volume capsules.
• An integrated prefilter layer upstream of the final membrane captures coarse particulates before they reach the sterilizing-grade surface, extending capsule throughput and service life.

Key Capsule Construction Features

• Single-use polypropylene capsule construction eliminates cleaning validation requirements, reducing the regulatory burden and turnaround time associated with reusable stainless steel filter housings.
• Polypropylene capsule housing supports autoclave sterilization at 121 degrees Celsius and withstands gamma irradiation exposure, accommodating both user-sterilized and factory-sterilized device configurations.
• The sealed polypropylene housing is individually integrity-tested during manufacturing, verifying membrane installation and housing seal quality before the device leaves the production facility.
• Hose barb connections enable direct integration with flexible tubing systems commonly used in laboratory and pilot-scale filtration setups.

From method development through scale-up to production, your capsule filter choice defines the balance between membrane performance, process integration, and the regulatory documentation trail that supports each filtration event. For biopharmaceutical manufacturing where retention validation and product recovery are equally critical, Supor membrane technology delivers the documented performance and ultra-low binding your process demands. Make the decision for consistency and reliability, ensuring that your laboratory maintains its reputation for high-quality, error-free output.

Sterilization Guidance

Standard autoclave cycles at 121 degrees Celsius are compatible with the polypropylene housing and membrane assembly, allowing preparation for sterile applications at the point of use.

For more information about chemical compatibility, please review our Chemical Compatibility Chart.

Bubble Point (psi)

51 psi

Burst Pressure (psi)

60 psi

Capsule Format

AcroPak 1500

Compliance Standards

USP Class VI <88>; Endotoxin < 0.25 EU/mL (LAL)

Construction

Polypropylene

Filling Bell (Yes/ No)

No

Filtration Area

1500 cm²

Flow Rate

2.2 L/min at 0.1 bar

Inlet Connection

1/2 in. straight hose barb

Length

22.9 cm

Material

PES

Max Batch Volume

150 L

Maximum Operating Pressure

60 psi

Maximum Operating Temperature (°C)

60 °C

Membrane Brand

Supor

Outlet Connection

1/2 in. straight hose barb

Pack Count

1

Pore Size (µm)

0.2

Pre-filter Pore Size

0.8

Prefilter (Yes/No)

Yes

Sterility

Nonsterile

Sterilization

Autoclave

Vent (Yes/ No)

Yes

Wettability

Hydrophilic

• Validation Support - Comprehensive manufacturer documentation including extractable profiles and bacterial challenge test data supports integration into regulated processes.
• Buffer Systems - Broad pH compatibility from 1 to 14 supports validated filtration across the full range of pharmaceutical buffer solutions.
• Process Compatibility - Supor PES membrane exhibits broad compatibility with aqueous buffers, aliphatic alcohols, and glycols across pH 1-14.
• Biologics Processing - Ultra-low binding PES membrane preserves therapeutic protein concentrations through production-scale processing.
• Scale-Up Filtration - Consistent Supor membrane performance from laboratory evaluation through pilot and full production batch volumes.
• Cell Culture Media - High-throughput filtration of tissue culture media with flow rates optimized for large-volume batch processing.
