Pall Acrodisc PTFE Syringe Filters, 0.2 µm, 13 mm, 300/Pk - 4423
Pall's proprietary membrane manufacturing capabilities put specialized media into the Acrodisc housing geometry. Gas and vent service calls for a hydrophobic syringe filter rated to the same sterilizing-grade pore size as its liquid counterpart. Chemically inert PTFE achieves sterile-grade retention in gas and vent service and resists attack from the harshest process chemistries. The polypropylene housing routes flow to minimize backpressure in service and leaves no seam for sample to bypass the membrane. Downstream equipment and work areas stay protected from airborne bacterial contamination once the vent path runs through the membrane.
Membrane Characteristics
- Ionic and metallic extractable levels stay very low
- Inert composition offers no nutrient source for microbial growth
- Strong oxidizing agents like nascent chlorine and concentrated sodium hydroxide cause no attack
- Low extractables keep the chromatographic background clean
- Hydrofluoric acid resistance holds even in fully acid-digested samples
Housing Characteristics
- Housing tolerates elevated-temperature aqueous and solvent sample filtration up to about 80°C without softening
- Stable across the full aqueous pH range in routine sample work
- Inert polyolefin wall contributes minimal sample adsorption to the filtrate
- Minimal intrinsic autofluorescence from the polypropylene housing supports background-sensitive fluorescence-based assay work downstream
Particulates left in your organic solvents and reagents carry downstream into the step that depends on a clean feed. Reliable solvent prefiltration keeps a stray particulate from carrying into your downstream work so your downstream method starts with a clean sample. Reach out to the Tisch Scientific team about minimum order quantities and shipping timelines for your filtration product selection.
Sterilization Guidance
The housing supports customer autoclave sterilization at 121°C for 30 minutes.
For more information about chemical compatibility, please review our Chemical Compatibility Chart.
- Bubble Point (psi)
- 15psi (IPA)
- Burst Pressure (psi)
- 100psi
- Connection Type
- Luer-Lock/ Luer Slip
- Construction
- Polypropylene (PP)
- Diameter
- 13mm
- Filtration Area
- 1.0cm²
- Flow Rate
- 10ml
- Holdup Volume
- < 30 µL
- Material
- Polytetrafluoroethylene (PTFE)
- Maximum Operating Pressure
- 100psi
- Maximum Operating Temperature (°C)
- 100°C
- Pack Count
- 300
- Pore Size (µm)
- 0.2
- Sterility
- Nonsterile
- Sterilization
- Autoclavable at 121°C for 15-20 min
- Wettability
- Hydrophobic
- Polymer GPC Prep - Clarifies polymer solutions in THF ahead of gel permeation chromatography, protecting columns from particulates.
- Pump Protection - Acts as a hydrophobic barrier that protects vacuum pumps from corrosive moisture and particulate damage.
- Automated Sample Prep - PTFE's chemical inertness holds up through repeated robotic filtration cycles without degrading or swelling over time.
- Dye and Pigment Analysis - Clarifies dye solutions in DMF, NMP, and other aggressive organics ahead of spectrophotometric color strength testing.
- Extractables Testing - Clarifies packaging material organic solvent extracts ahead of LC-MS analysis, keeping background low for leachable detection.
- Chemical Synthesis - Resists aggressive organic solvents and corrosive acids for compatibility with harsh synthetic reaction mixtures.
