PES Syringe Filters, 0.05um, 13mm, Luer-Lok/Luer Slip, Nonsterile, 100/Pk SKU: SF16008

Polyethersulfone (PES) Syringe Filters - SF16008

Featuring ultrafiltration-grade polyethersulfone membrane technology with 0.05µm pore size engineered for viral clearance and endotoxin removal in small-volume applications. Laboratory professionals working with precious biological samples benefit from compact 13mm format delivering exceptional retention capabilities without sacrificing sample recovery. Tisch Scientific combines precision ultrafiltration membranes with robust polypropylene construction to provide reliable virus removal performance in biotechnology and pharmaceutical research environments.

Key Polyethersulfone (PES) Membrane Characteristics

• Naturally hydrophilic membrane enabling immediate filtration without pre-wetting steps
• Ultra-fine 0.05µm pore structure providing virus removal and macromolecule retention
• Low protein binding characteristics preserving sample integrity during ultrafiltration
• Membrane thickness of 100-160µm, ensuring structural stability under operating pressure
• Chemical resistance to aqueous solutions and compatible organic solvents

Key Construction Characteristics

• Compact 13mm diameter optimized for processing small-volume precious samples
• Integrated PP prefilter extending membrane life by removing larger particulates
• Minimal holdup volume of 10µL, maximizing recovery of valuable materials
• Dual Luer-Lok/Luer Slip compatibility ensures universal syringe connections

SF16008 syringe filters deliver controlled flow rates of 3ml through a 1.09cm² active membrane area, balancing ultrafiltration efficiency with your processing time requirements for small-volume applications. A bubble point specification of 37.71psi provides reliable membrane integrity verification essential for validated viral clearance processes. Autoclave compatibility at 121°C for 30 minutes or gamma sterilization options ensure flexibility in meeting your laboratory's contamination control standards while maintaining operational temperatures up to 60°C.

For more information about chemical and material compatibility, please review our Chemical Compatibility Chart.

Bubble Point (psi)

37.71psi

Burst Pressure (psi)

87psi

Connection Type

Luer-Lok/ Luer Slip

Diameter

13mm

Filtration Area

1.09cm²

Flow Rate

3ml

Holdup Volume

10μL

Material

Polyethersulfone (PES)

Maximum Operating Pressure

87psi

Maximum Operating Temperature (°C)

60°C

Membrane Thickness (µm)

100-160μm

Pack Count

100

Pore Size (µm)

0.05

Prefilter (Yes/No)

Yes

Prefilter Material

PP

Sterility

Nonsterile

Sterilization

Autoclave 121°C for 30min/ gamma 25kGy

Volume Throughput (ml)

10ml

Wetability

Hydrophilic

• Virus Removal - Eliminate viral particles from small-batch biologics
• Endotoxin Clearance - Remove pyrogens from injectable preparations
• Protein Concentration - Retain therapeutic proteins while removing salts
• Mycoplasma Filtration - Clear contamination from cell culture samples
• Nanoparticle Research - Size-based separation of nanomaterials
• Ultrapure Sample Preparation - Generate particle-free solutions for analysis
