Thumbnail Filmstrip of PTFE Syringe Filter, 0.45 µm, 25 mm, Luer-Lok/Luer Slip, Non-Sterile, 100/Pk Images
Tisch PTFE Syringe Filters are used for the filtration of liquid samples that contain insoluble impurities and are made from high quality materials with very low levels of extractables. The housing material is high quality polypropylene which is chemically resistant to a wide range of solutes and solvents.
These filters are constructed so that the sample must pass through the membrane, not leak around it. They are easy to use. They may be used with any luer-lock syringe. The 13mm filters can filter 5 to 10mL of sample and have a retention volume of only 28µL.
Product Uses & Filtration Applications
- Organic Solvents
- Acids
- Alcohols
- Bases
- Aromatics
- Venting Applications
| PRODUCT SPEC TABLE | |
|---|---|
| Tisch Product Code | SF14469 |
| Filtration Area | 4.08 cm^2 |
| Wettability | Hydrophobic |
| Pore Size | 0.45 µm |
| Filter Size | 25 mm |
| Input Connector | Luer-Lok |
| Output Connector | Luer Slip |
| Maximum Operating Temperature | 130° C |
| Bubble Point | 0.1 psi |
| Burst Pressure | 87 psi |
| Flow Rate | 24 ml/min @ 10 psi |
| Holdup Volume | 20 |
| Volume Throughput | 100 ml |
| Housing Material | Polypropylene (PP) |
| Sterility | Nonsterile |
| Sterilization | Autoclave: 121° C for 30 Minutes Gamma: 5kg, for 8 Hours |
| Pack Size | 100 |
| Incompatible With | Aqueous Samples Without Rewetting. |
- Bubble Point
- 0.1psi.
- Burst Pressure
- 87psi.
- Connection Type
- Luer-Lok/ Luer Slip
- Construction
- Polypropylene (PP)
- Diameter
- 25mm
- Filtration Area
- 4.08cm²
- Flow Rate
- 24ml/ min @ 10psi.
- Holdup Volume
- 20ml
- Incompatibility
- Aqueous samples without rewetting
- Material
- Polytetrafluoroethylene (PTFE)
- Maximum Operating Temperature
- 130°C
- Pack Count
- 100
- Pore Size (µm)
- 0.45
- Sterility
- Nonsterile
- Sterilization
- Autoclave: 121°C for 30 minutes/ Gamma: 5kg, for 8 hours
- Volume Throughput
- 100ml
- Wetability
- Hydrophobic
