Tisch Scientific PTFE Syringe Filters, 0.1 µm, 13 mm, 100/Pk - SF18084
Tisch Scientific reduces per-unit costs for laboratories that place blanket purchase agreements or large-quantity orders. Gas and vent service calls for a hydrophobic syringe filter rated to the same sterilizing-grade pore size as its liquid counterpart. The PTFE membrane withstands aggressive organics that degrade other media while delivering sterilizing-grade gas and vent filtration and handles concentrated acids and bases. The PP housing sustains efficient flow on viscous samples while resisting degradation from routine sample matrices and delivers a chemically clean filtrate to the downstream step. A vent or gas line stays free of airborne bacteria once a hydrophobic, sterilizing-grade membrane is in the path.
Membrane Characteristics
- High membrane porosity, 70 to 80 percent void volume, delivers high flow at low pressure
- Insolubility in all known organic solvents avoids swelling and pore distortion
- Non-wetting pore surface blocks liquid water while passing water vapor freely
- Node-fibril microstructure resists compaction under sustained operating pressure
- Hydrofluoric acid resistance holds even in fully acid-digested samples
Housing Characteristics
- Minimal ionic background from the polypropylene housing supports ion chromatography and trace-metal ICP-MS sample preparation
- Polypropylene density near 0.90 g/cm3 keeps housing weight low relative to denser engineering plastics
- Rated operating pressure supports filtration of high-resistance and viscous samples without housing distortion
- Thermal-bonded construction keeps adhesives out of the fluid path
Particulates left in your organic solvents and reagents carry downstream into the step that depends on a clean feed. Reliable solvent prefiltration keeps a stray particulate from carrying into your downstream work so your downstream method starts with a clean sample. Start a live chat with the Tisch Scientific team about packaging, unit count, and ship-date for your filtration order.
Sterilization Guidance
Standard autoclave cycles at 121°C for 30 minutes prepare the device for sterile workflows.
For more information about chemical compatibility, please review our Chemical Compatibility Chart.
- Bubble Point (psi)
- 26.11(absolute ethyl alcohol)
- Burst Pressure (psi)
- 87psi.
- Connection Type
- Luer-Lok/Luer Slip
- Construction
- PP
- Diameter
- 13mm
- Filtration Area
- 1.09cm²
- Flow Rate
- 3ml
- Holdup Volume
- 10μL
- Incompatibility
- Aqueous samples without rewetting
- Material
- Polytetrafluoroethylene (PTFE)
- Maximum Operating Pressure
- 87psi
- Maximum Operating Temperature (°C)
- 60°C
- Membrane Thickness (µm)
- 80-140μm
- Pack Count
- 100
- Pore Size (µm)
- 0.1
- Sterility
- NonSterile
- Sterilization
- Autoclave 121°C for 30min/ Gamma 25kGy
- Volume Throughput (ml)
- 10ml
- Weight
- 0.19
- Wettability
- Hydrophobic
- Toxicology Screening - Clarifies protein-precipitated serum, plasma, and urine extracts ahead of LC-MS or GC-MS drug screening analysis.
- Battery Electrolyte Prep - Clarifies lithium-ion battery electrolyte in carbonate solvents ahead of GC-MS purity and impurity analysis.
- Polymer GPC Prep - Clarifies polymer solutions in THF ahead of gel permeation chromatography, protecting columns from particulates.
- Dissolution Testing - Stops the dissolution reaction and clarifies samples, with low API binding for accurate potency quantitation.
- Photoresist Filtration - Clarifies photoresist solutions in organic casting solvent ahead of spin-coating, reducing particulate defect risk.
- Trace Metals Analysis - PTFE's low metal-extractable profile clarifies acid-digested samples for clean, low-background ICP-MS and ICP-OES results.
